Cables
RP-CA-02
Plain polyester tape
Plain Polyester Tape (PET Tape)
High strength plain polyester tape for cable insulation, wrapping and reinforcement.
✓
Reliable Performance
Consistent quality for demanding applications
✓
Temperature Resistant
Performs across practical operating conditions
✓
Strong Adhesion
Excellent bonding and conversion stability
✓
Compliant Supply
Produced for industrial quality expectations
Product Overview
High-tensile polyester (PET) film tape used for cable core wrapping, insulation, sheathing separator, and sheathing reinforcement. Provides excellent dielectric strength, heat resistance, and mechanical protection.
Key High-Performance Features
✓
High mechanical strength and puncture resistance
✓
Excellent electrical insulation properties
✓
Good temperature resistance up to 150 °C
✓
Clean unwind performance
Industrial Applications
Insulation support – adds an extra electrical insulation layer.
Separator layer – prevents different cable components from sticking together.
Core wrapping/binding – holds cable cores together before sheathing.
Shield protection – protects insulation from metallic shields and braids.
Armor bedding – cushions cable cores from steel armor.
Technical Specifications
Film Thickness
8–350 µm
Density
1.4 Kg/cm3
Tensile Strength
>1250 Kg/cm3
Elongation at Break
30 %
Roll Width
Custom
Core ID
76/152 mm
Pallet
Edge-protected, stretch wrapped
Product Lineup & SKU Matrix
Standard order configurations and formats. Custom sizing, width, and gauge tolerances are available upon query.
| SKU | Width | Length | Thickness | Use |
|---|---|---|---|---|
| RP-CA-02-A | 1/2" (12.7 mm) | 1 000 ft | 25 µm | Core wrapping |
| RP-CA-02-B | 1" (25.4 mm) | 1 000 ft | 50 µm | Insulation support |
